Special patent front-positioning blade design especially for large hallow material like bottles and barrels, the rotary blades and stationary blades are settled with a V-shaped angle leading the crushing subject into rotary center, with large cutting angle, excellent efficiency, even flake output and less powder occurred.
Specifications for big hollow plastic soundproof industrial crusher
Model |
AT-20HP-BV |
AT-30HP-BV |
AT-50HP-BV |
AT-75HP-BV |
|
Grinding Chamber(mm) |
530*400 |
530*400 |
830*520 |
1100*740 |
|
Power |
KW |
15 |
22 |
37.5 |
55 |
HP |
20 |
30 |
50 |
75 |
|
Grinding Capacity(KG/H) |
350-550 |
400-550 |
750-1080 |
800-1200 |
|
Stationary Cutter |
2 |
2 |
4 |
4 |
|
Rotary Cutter |
3 |
3 |
6 |
9 |
|
Mesh Size(mm) |
Φ14 |
Φ14 |
Φ16 |
Φ16 |
|
Barrel Volume(L) |
30L |
30L |
100L |
200L |
|
Barrel Size(mm) |
Φ330*490 |
Φ330*490 |
Φ420*780 |
Φ600*1000 |
|
Dimension (L*W*H*H1 mm) |
1430*1120*1930*1458 |
1430*1120*1930*1458 |
2000*1610*2690*2030 |
2450*1940*3260*2510 |
Appications for big hollow plastic industrial crusher:
Industrial crusher machine is used for crushing big hollow plastics such as water tank, bucket, oil-can, plastic cabinet, container, jar, jerrycan, drum, pet bottles, plastic chair, beer case, call bumper, and shell for Battery, Television, etc.
